KOMADA Hydraulic Manual Stacker

Specifications :

Product code		RSD 1016	RSD 1516	RSD 2016
Base
Capacity	kg	1000	1500	2000
Load Center (C)	mm	400
Type of lifting		Hand/Foot Pump
Operating Type		Walkie
Wheel
Material	mm	Nylon
Qty Steering/Loading wheel	mm	2/2
Wheel Base	mm	1140
Loading Wheel	mm	Ø80 x 60
Steering Wheel	mm	Ø180 x 50
Dimension
Min.fork height (H1)	mm	90
Max.fork height (H2)	mm	1600
Fork Outside width	mm	320-720	340-830	340-740
Fork Inside width	mm	20-320	20-340	20-340
Fork Length (L1)	mm	1000 (cover fork)
Single Fork Size	mm	150/60	160/60	160/60
Overall Length (L)	mm	1525	1525	1525
Overall Width (E)	mm	790	890	790
Overall Height (H)	mm	1985	2085	2085
Min. turning radius (Wa)	mm	1400
Peformance
Foot pedal cycles to max (laden)	mm/s	≤76	≤110	≤110
Lowering Speed (laden/unladen)	mm/s	Controlled

*Product colours depends on stock: Red / Yellow

The drawing of Hydraulic Manual Stacker - RSD 1016, 1516, 2016

KOMADA Hydraulic Manual Stacker -RSD1016, RSD1516, RSD2016

In regards to material handling especially pallets, KOMADA Hydraulic Manual Stacker serving as fully manual stacker in moving pallets from 1 area to another. With its choices of model that with different dimensions offered, effectiveness of the users' business operation will be enhanced and improved in the long run as less time will be needed in moving the pallet.
